MESSE10: Passive Surround Monitor Controller

SM Pro Audio introduce the MPATCH 5.1      25/03/10

MESSE10: Passive Surround Monitor Controller


Designed to provide true passive analog control over surround studio monitoring systems SM Pro Audio's new MPATCH 5.1 employs a newly designed multi gang passive switching system with incredible accuracy which in the past would have only been possible in units costing 1000's of dollars.
No power has to be connected to the MPATCH 5.1 in order for the unit to operate, the power is only needed for LED indication, it is a totally passive surround controller.
A 25 pin D-SUB input connector provides six surround (5.1) and two stereo input channels. In addition to a surround speaker system, a stereo monitoring pair can be connected to the MPATCH 5.1. An additional 4 stereo input allows for other unbalanced line level input to be connected to the MPATCH 5.1 (such as DVD players, CD players etc).
Adjustment of the attenuation in the MPATCH 5.1 is handled by a 12 gang switching system utilising accurate precision metal film resistors which eliminates issues currently found in other passive systems at lower volumes.
The MPATCH 5.1 is ideally suited for:

  • Surround and stereo production
  • Film and video mixing
  • Video and game production
  • multimedia production
  • home entertainment systems
  • DTS, SACD, DVD-V and DVD-A authoring

Features

  • Balanced inputs (D-SUB)
  • Unbalanced RCA surround inputs
  • Balanced TRS stereo inputs
  • Unbalanced RCA stereo inputs
  • Dual Balanced XLR L/R outputs
  • Balanced TRS surround outputs
  • Balanced slave output (D-SUB)
  • Rotary analog stereo volume controls
  • 8 output selector switches with mutes
  • -20dB pad switch
  • Stereo/Mono switch
  • Master Mute Switch

Pricing and Availability:
TBA More information:
