MESSE08: 128 Channels Of Audio For Laptops

RME announce the MADIface 128-Channel 192 kHz MADI ExpressCard      12/03/08
MESSE08: 128 Channels Of Audio For Laptops


At Musikmesse RME are presenting the new MADIface, which they tell us is the world’s first portable MADI solution for Laptops, providing a stunning 128 channels of audio at up to 192 kHz.
RME say that the HDSPe ExpressCard MADI is a true PCI Express solution, which consequently takes full advantage of the new format, achieving significant performance gains in multitrack audio.
Here’s the rest of what they say in their own words…
Consisting of the HDSPe ExpressCard MADI and a small breakout box, the MADIface offers full MADI power: 64 channels input and 64 channels output, up to 192 kHz sample rate, in MADI embedded MIDI transmission, complete TotalMix that is even remote controllable and has all features of the 'bigger' HDSPe MADI, as well as lowest latency and CPU-load. To make the usage as comfortable as possible, the power for the breakout box is provided directly by the ExpressCard, so no external power supply is required.
The MADIface is fully compatible to all devices with MADI interface. Of course it can be used perfectly in combination with RME's own MADI series products. For example with the ADI-648 an 8 x ADAT optical PC interface is realized, unbeatable in price and performance. And with the ADI-6432 a bidirectional AES/EBU frontend with 64 channels is set up hassle-free.
Full 64 channel support can also be found in the hardware mixer TotalMix. All 64 inputs and 64 playback channels can be routed and mixed to 64 physical outputs completely freely, which translates to an 8192 channel mixer. TotalMix can be completely remote controlled via MIDI. Furthermore, the hardware delivers RMS and peak level meters for full control over 192 audio channels at minimal CPU load.
While many MADI-based devices require an additional word clock or AES line, the MADIface (like all RME devices) uses SteadyClock(TM) to extract the reference clock at lowest jitter directly from the MADI signal, making long-distance connections even more convenient. Although not available at the MADIface itself, word clock input and output are thus available when using another RME MADI device.
MADIface offers a virtual MIDI port within the driver. Mainly intended for remote controlling further RME devices, it can also be used to send and receive usual MIDI data. The MIDI data are invisibly inserted into and transmitted by the MADI signal. Therefore a physical access is given at the RME interface connected to the MADIface.
Included software:
  • DIGICheck for Windows: Spectral Analyser, professional level meter for 2, 8, or 64 channels, Vector Audio Scope, Global record, various other audio analysis tools.
  • Drivers: Windows 2000/XP/Vista/64 (full ASIO multi-client operation of WDM, GSIF 2.0 and ASIO 2.0), Mac OS X Intel (Core Audio and Core MIDI).
Pricing and Availability:
TBA More information:
  • www.rme-audio.de
